In the transformer manufacturing and high-voltage power equipment industry, the choice of insulation materials directly impacts the safety, durability, and operational efficiency of the equipment. Among numerous insulation materials, 30mm-100mm electrical laminated wood and processed parts are widely recognized as an ideal choice due to their excellent mechanical strength, stable electrical performance, and good machinability.
Electrical laminated wood is an insulating structural material. It uses high-quality birch or beech veneer as raw material, impregnated with insulating resin, and then laminated under high temperature and pressure. It has high density, good oil absorption, and high voltage resistance. It is commonly used in oil-immersed transformers, reactors, and high-voltage switchgear. The 30mm-100mm specification can meet the needs of common insulation structural parts in transformers from small to large sizes.
During the impregnation with insulating resin and high-temperature pressing process, electrical laminated wood exhibits high breakdown voltage and low dielectric loss. It can operate stably in transformer oil environments for extended periods, ensuring safe equipment operation.
Compared to traditional insulating paperboard or ordinary laminates, 30mm-100mm electrical laminate wood exhibits greater mechanical strength and creep resistance in the thickness direction. It is suitable for support structures subjected to significant mechanical stress, such as upper and lower pressure plates, support strips, pads, and trays.
Under oil immersion conditions, electrical laminate wood can stably absorb insulating oil, maintaining dimensional stability and resisting deformation. It can adapt to temperature changes and thermal cycling during long-term transformer operation.
30mm-100mm electrical laminate wood can be processed into various precision insulating components according to transformer structural design requirements, including:
Pressure plates (upper and lower pressure plates)
Support strips, pads
Insulating rings, trays
Partitions, support strips
Irregularly Shaped Structural Components
Through CNC machining, milling, drilling, grooving, and other processes, it can meet the customization needs of high-precision and complex structures.
High-quality processed parts depend not only on the material itself but also on the level of processing technology:
CNC precision machining
Multi-axis cutting and drilling
High-precision dimensional control (±0.1mm)
Smooth, burr-free surface
No delamination, no bubbles
Dense and uniform structure
No edge cracks
Processing quality directly affects the assembly and operational stability of transformers.
When selecting 30mm-100mm electrical laminate wood and processed parts, it is recommended to focus on the following points:
Ensure that the product complies with relevant domestic and international standards such as GB/T 20633 and IEC 61061.
High-precision processed parts have strict requirements for thickness tolerance, typically controlled within ±0.1mm.
Prioritize suppliers with CNC machining capabilities and the ability to provide customized drawing services.
Transformer manufacturing cycles are long. And suppliers should have stable large-volume supply capabilities.
Suppliers must provide key performance test data such as breakdown voltage, density, moisture content, and oil absorption rate.
Addressing the diverse structures and numerous non-standard parts in transformers, our professional electrical laminate wood processing services offer:
Supports CAD drawing integration and processing to your specific needs.
Covers thicknesses from 30mm to 100mm, supporting various length and width combinations.
Meets the needs of small-batch, rapid delivery during the R&D and prototype stages.
Provides moisture-proof and contamination-proof packaging tailored to the characteristics of insulating components, ensuring quality upon arrival.
In transformer insulation systems, structural components not only provide electrical isolation but also affect overall mechanical stability and long-term operational reliability. 30mm – 100mm electrical laminate wood and its processed parts, with their excellent comprehensive performance, have become the industry’s preferred material.
If you are looking for a stable and reliable supplier of electrical laminate wood processed parts, please contact us for technical support and product solutions.
We will provide the most suitable materials and processing services based on your transformer structure and performance requirements.
If you need our products please write down any questions, we will reply as soon as possible.
